The ultimate resilient power platform for modern homes—combining instant-response flywheel technology with reliable lithium battery storage for uninterrupted energy, peak shaving, and outage protection.
Flywheel, battery, inverter/controller, enclosure, and internal sensors.
Typical full system with professional installation, commissioning, and permitting.
Sized for a two-bedroom residence with room for surge loads and peak events.
Why hybrid? Energy is stored as rotational power inside a high-speed flywheel for instantaneous response and within advanced lithium batteries for long-duration supply.
Result: Whole-home coverage that handles daily consumption, peak surges, and outage protection with no single point of failure.
| Feature | Value |
|---|---|
| Daily home energy | 24 kWh (2-bedroom home) |
| Battery storage | 16 kWh (48V, 350Ah LFP) |
| Flywheel storage | 8 kWh (1.2 m steel barrel) |
| System footprint | 2.0 m × 2.0 m room |
| Installation | Indoor — garage, shed, or utility room |
Blue illumination indicates the flywheel chamber, silver panels protect the battery pack, and the orange fascia houses the inverter and control electronics.
Flywheel instantly covers motor and compressor startup loads so the battery experiences minimal stress.
The lithium pack provides overnight or multi-hour coverage, maintaining critical circuits through grid outages.
Dual storage paths, safety braking, and real-time monitoring safeguard against battery or grid faults.
Upgrade to composite flywheels, add modular battery packs, or scale output beyond 50 kWh for estates, commercial sites, or microgrids. Custom three-phase and remote-ready builds are available.
Discuss advanced configurations
Premium home installation showing the illuminated flywheel, silver battery enclosure, and orange inverter controls arranged for intuitive access.
| Component | Description | Role | Retail (USD) |
|---|---|---|---|
| Flywheel barrel | Steel/composite, 1.2 m diameter, 0.3 m thick, 1.3 tons | Stores rapid-response energy for surges | $14,900 |
| Battery pack | 48V, 350Ah LFP battery (16 kWh) | Supplies steady overnight and outage power | $7,900 |
| Motor/generator | 10–20 kW brushless, bi-directional | Charges and discharges the flywheel | $3,900 |
| Inverter/controls | 10–20 kW smart wall-mounted controller | Manages AC/DC power flow across the system | $4,200 |
| Safety & enclosure | Steel frame, fire-rated room or cabinet | Delivers vibration, fire, and access protection | $1,800 |
| Base system hardware price | $34,900 | ||
Isometric layout: blue = flywheel, gray = battery, orange = inverter and controls.
Ideal for solar contractors, developers, and distributors.
| Subsystem | Main parts | Unit cost (USD) | Retail allocated |
|---|---|---|---|
| Flywheel system | Barrel, bearings, vacuum housing, motor/generator, frame, sensors | $10,000 – $13,000 | $14,900 |
| Battery system | LFP pack, BMS, disconnects, safety wiring | $6,000 – $7,000 | $7,900 |
| Power & controls | Inverter, charger, PLC, user display/panel, wiring | $2,500 – $3,200 | $4,200 |
| Safety & mounting | Frame, brakes, enclosure, cooling | $1,200 – $1,700 | $1,800 |
| Total BOM | $20,000 – $25,000 | $34,900 |
Pricing reflects the true cost of engineering, safety certification, and long-term support. Development, installation, and commissioning are added per project to maintain reliability and service quality.
Request a hardware quote, turn-key installation, or installer pricing.
ioncoreenergy@gmail.com • Chat with us on Telegram
Site visits, volume orders, and custom system sizing available worldwide. Turn-key packages include hardware, installation, commissioning, and support after site assessment.
